Gester International Co., Ltd
| Place of Origin: | China |
|---|---|
| Brand Name: | GESTER |
| Certification: | CE, ISO |
| Model Number: | GT-C18 |
| Minimum Order Quantity: | 1 set |
| Packaging Details: | wooden packaging |
| Delivery Time: | 10-30 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 set/month |
| Power: | AC220V | Usage: | Pilling And Snagging Properties Of Fabrics |
|---|---|---|---|
| Product Name: | ICI Pilling Box | Warranty: | 12 Months |
| Color: | Black | Service: | Online Support, Installation And Training |
| High Light: | ISO 12945.1 ICI Pilling Box Tester,4 Boxes ICI Pilling Tester,ISO 12945.1 ICI Pilling Box Tester |
||
|
Application:
ICI Pilling Box Tester is used to rapidly replicate pilling on fabrics in a fraction of the time due to normal wear. then determine surface pilling and snagging properties of both in woven and knitted fabrics.
ICI Pilling Tester complies with ISO12945-1, BS 5811 etc. ICI pilling tester uses a universal drive system with 2 or 4 position, electronic digital counter, and sample mounting fixture. The machine accepts ICI Pilling boxes and ICI pilling drums.
Specimens are mounted on polyurethane tubes and tumbled randomly under defined conditions in a cork lined box. Pilling is assessed visually after a defined period of tumbling. Contact us for more information about ICI pilling test method.
Standards: GB/T4802.3, ISO 12945.1, BS5811, IWS TM152 |
|
Model |
GT-C18 |
||
|
Number of pilling boxes |
2 Boxes |
4 Boxes |
9 Boxes |
|
Rotational speed |
60±2 rpm |
||
|
Internal dimensions |
235×235mm |
||
|
Count range |
0-99999 |
||
|
Polyurethane sample tubes |
External dia.: 31.5±1mm; L:140±1mm; thickness: 3.2±0.5mm; |
||
|
Power supply |
AC 220V 50/60HZ |
||
|
Dimensions (L x W x H) |
120x 50x 50 cm |
120x 50x80 cm |
140x 50x 160 cm |
|
Weight |
40kg |
60kg |
180kg |
|
Standards |
GB/T4802.3, ISO 12945.1, BS5811, IWS TM152 |
||
|
Standard accessories |
6pcs /each box |
Cork lining |
|
4pcs /each box |
Polyurethane sample tubes |
|
|
1pc |
Sample template |
|
|
1pc |
Power line |
|
|
Optional accessories |
Optional |
Pilling specimen mounting device |
|
Optional |
Standard photographs |
|
|
Optional |
GT-C78 Pilling Assessment Box |
|
|
Optional |
M&S Random Tumble Pilling/ Snagging Drum complete with Liner, Step, and 8 polyurethane sample mounting tubes with locking rings - M&S suppliers only. |
