Gester International Co., Ltd
| Place of Origin: | China |
|---|---|
| Brand Name: | GESTER |
| Certification: | CE, ISO |
| Model Number: | GT-MB04 |
| Minimum Order Quantity: | 1 set |
| Packaging Details: | wooden packaging |
| Delivery Time: | 10-30 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 200 set/month |
| Power: | Manual | Usage: | Toys Testing Equipment |
|---|---|---|---|
| Warranty: | 1 Year | Application: | Toys And Toy Materials |
| Technology: | Professional | Gester: | SGS Audited Supplier,TUV |
| High Light: | 16 CFR 1500 Toys Testing Equipment,450g Toys Testing Equipment,16 CFR 1500 Sharp Point Tester |
||
|
Application: Sharp Point Tester is used to determinate that points on toys and other articles intended for use by children under 8 years of age, and such points exposed in normal use or as a result of reasonably foreseeable damage or abuse of such toys and articles, present a potential risk of injury by puncture or laceration. Standards: ISO 8124-1 EN-71-1 16 CFR 1500 ASTM F 963 GB6675-2 |
Test Principle
|
The device has a slot with 0.04 inches width and 0.045 inches long rectangular opening, the two reference sizes sharpness are inserted into the depth of 0.015 inches deep hole of the sensor head. And overcome the spring of 0.5 pound elastic to cause the sensor head to move 0.005 inches again. That was identified as sharp point. |
| Model | GT-MB04 |
| Bottom slot | 0.040 x 0.045 inch (1.15 x 1.02mm) |
| Touched depth (Slotted vane thickness) | 0.015 inch (0.38mm) |
| Spring elastic force | 0.5LB@0.005inch |
| Power | 12V 23A Battery |
| Dimensions | 112x16x16mm |
| Weight | 450g |
